Stirrers :

Ax1

AX1

The AX1 is made for homogenisation, suspension creation at low speed as well as heat transfer. It is the propeller with the largest manometric head, offering a low shear rate.



PROPELLER DESIGN

Definition basis: Profiled propeller with slim blades
Number of blades: 3
Rotation direction: Clockwise or anticlockwise (according to the required flow)



FLOW OF AX1 STIRRING DEVICES - USE

Blown flow:
Vertical from top to bottom (axial preponderance)
Vortex creation
A stirrer equipped with a blown AX1 can be mounted centred with counter-blades or offset without counter-blades.
Low shear rate at max. speed (low peripheral speed)
Risk of the introduction of gas into the mixture


Applications:
Mixtures, heat transfer, simple dissolution, creation of suspension and holding in suspension.

Suction flow:
Vertical from bottom to top  (axial preponderance)
Bubbling on a liquid surface
A stirrer equipped with a suction AX1 can be mounted centred with counter-blades or offset without counter-blades.


Applications:
Mixtures, foaming product mixtures, heat transfer, simple dissolution, creation of suspension and holding in suspension.
